Falco

Falco is the latest generation of fixed VOC detectors that continuously detect a wide range of volatile organic compounds (VOCs) using patented photoionisation detection (PID) technology.
Unique to this fixed VOC detector is its revolutionary ‘typhoon technology’ safeguarding the PID sensor from condensing moisture for added reliability in severe weather conditions. In addition, the PID sensor incorporates patented Fence Electrode Technology, which virtually removes the effects of airborne humidity and protects from contamination.
Specifications:
Sensor:
• Photoionisation with 10.6 eV lamp.
Detection ranges and sensitivity:
• 10.0 ppm  -  0.001 ppm.
• 50.0 ppm  -  0.01 ppm.
• 1,000 ppm - 0.1 ppm.
• 3,000 ppm - 1 ppm.
Detection time (T90):
• <30 seconds (diffused)**
User interface:
• Display: OLED high contrast white on black: 128 (w) x 64 (h) pixels Screen, size: 35 mm (w) x 17.5 mm (h).
• 5 magnetic switches with LED confirmation (up, down, left, right & enter).
• Magnetic actuator supplied.
Input power:
• Working voltage: 12 to 40 Vdc Max. power: 7 watts.
Status indicator:
• Bright visible status indicator: Red, Amber, Green.
Outputs:
• 4 to 20 mA (active and passive).
• RS485 supports Modbus® protocol.
• Relay x 2 SPST (60 Vdc 2A) – configurable.
Mounting points:
• 2 x M8.
Environmental specification:
• Without pump: -40oC to 60oC.
• With pump:-20oC to 60oC.
• 0-100% RH and condensing humidity.
Mechanical interface:
• 2 x cable entry points with 3/4” NPT threads (left and right).
• 2 x 3/4” NPT to M20 Stainless steel (supplied).
Dimensions:
• Without pump: 200 (H) x 190 (W) x 125 (D) mm
• With pump: 290 (H) x 190 (W) x 125 (D) mm
Certification:
• II 2G Ex d ib IIC T4 Gb ISO9001:2008.
